3.2. Installations of temp sensor
Attention: Temperature sensor should be
installed in sauna room but not directly above
sauna heater, the height must be a minimum
of 1800mm from floor. The horizontal distance
to sauna heater must exceed 500mm, refer to
figure 3.
Please drill a hole (diameter 16mm ), and then
nail down the sensor in the sauna room,
connect the temp sensor wire into the 2 pin
plug on circuit board of central control box, see
figure 1.
