SteelFlex XT-3300 - Page 8

Treadmill XT-3300 VERSION
The assembly of the parts S/N：0405
Page 8 of 11
M3×8 Round Cross Tap
Screw
PC Board
9530-048
ψ14×ψ25×2t Rubber Washer
M3 Bakelite Washer
Stop Switch Assembly
Heart Rate PC Boar
d
9530-022
Hall Sensor
9545-006
Wire Holde
r
9260-016
PC Board Wire
9542-063
Hand Pulse Connector
Wiring 9542-013
Hand Pulse Connecto
r
Wiring 9542-013
