HARDWARE INSTALLATION
9 10
SETUP PS4 PRO AND ORIGINAL
01 Connect the main headset cable from the
headset to the GameDAC
02 Connect the USB audio cable
01
from the
GameDAC to the front of the PS4
03 Connect the Optical Audio Cable
02
from
the GameDAC to the back of the PS4
GameDAC SETTINGS
01 Press and hold the control wheel
06
to enter the main menu
02 Select Input, then click the control wheel
06
to edit
03 Choose the PS4 mode
PS4 AUDIO SETTINGS
SOUND AND SCREEN > AUDIO OUTPUT SETTINGS
Primary Output Port Digital Out (Optical)
Audio Format (Priority) Bitstream (Dolby)
DEVICES > AUDIO DEVICES
Output to Headphones Chat Audio
0201

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the SteelSeries GameDAC and is the answer not in the manual?

SteelSeries GameDAC Specifications

General IconGeneral
Output level49 mV
Amplifier class-
Audio output channels- channels
Peak power per channel- W
Signal-to-Noise Ratio (SNR)109 dB
Total Harmonic Distortion (THD)0.0032 %
Headphone outputs1
Headphone connectivity3.5 mm
USB 2.0 ports quantity2
PurposeHome
EqualizerYes
Product colorBlack
Connectivity technologyWired
Weight and Dimensions IconWeight and Dimensions
Width- mm
