LOCATION OF CONTROLS
1. Dust Cover
2. LCD Display
3. Remote Sensor
4. FM Stereo LED Indicator
5. Power LED Indicator
6. Band Selector Switch
7. Off/On/Radio Selector
8. Finalize Button
9. CD I – CD Door Open Button
10. CD I – CD Play/Pause
Button
11. CD I – CD Stop
Button
12. CD I – CD Skip Up
/ Down Button
13. CD I – Program Button
14. CD I – Repeat Play Button
15. CD I – CD Door
16. Tape Function Button
17. Phono Function Button
18. Volume Up “ + “/Down “ – “Buttons
19. CD I/Aux Function Button
20. CDII Function Button
21. Tuning Knob
22. Track Separation “ “ Button
23. CDII – CD Door Open Button
24. CDII – CD Play/Pause
Button
25. CDII – CD Door
26. X-BASS On/Off Button
27. CDII – CD Stop
Button
28. 3.5mm dia. Headphone Jack
29. 3.5mm dia. Aux-In Jack
30. CDII – CD Skip Up
/ Down Button
31. Record
Button
32. Erase Button
33. LED Dial Pointer
34. Tape Forward / Eject Button
35. Cassette Door Cover
36. 45rpm Spindle Adaptor
37. Turntable Speed Selector
38. Tone Arm Rest
39. FM Wire Antenna
40. Speaker Terminals (Right + Left)
41. Line Out Socket
42. Auto Stop Switch
43. AC Cord
44. Subwoofer Socket
CAUTION:
USAGE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED
HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE. THEREFORE, THIS UNIT SHOULD NOT BE ADJUSTED
OR REPAIRED BY ANYONE EXCEPT QUALIFIED SERVICE PERSONNEL.
E-1
