Appendix
Appendix n A.05 Comfort Plus
PARTS LIST - 3100 SERIES CONTINUED
When ordering parts, please include the system model and serial numbers.
DWG.
REF.
NO.
DESCRIPTION
3120
ITEM NO.
31 Core Blower Limit Switch 130D 1012006R
32 Discharge Air High Limit Switch 160D 1012008R
33 Discharge Air Sensor 1041536R
34 Core Temperature Sensor 1041625R
35 Bottom Micropore Insulation Panel 1050124
36 Transformer 75VA 1017039
37 Breaker 15 Amp 1024000R
38 Breaker 60 Amp 1024002R
39 Interface Cable, 36" 1010016
40 Interface Cable, 12" 1010012
41 Outdoor Sensor - Knockout Style - 40' 1302044R
" Outdoor Sensor - Knockout Style - 8' 1302033
42 Faceplate Label 1159029
43 Time Clock Module (optional) 1301014
44 Harness Motor ECM Low Voltage 1011703
45 Harness Line Voltage Variable Speed 1011702
46 Harness Process Output Variable Speed 9 Pin
1011705
47 Harness Process Input Variable Speed 15 Pin
1011704
48 PCB ECM Motor Interface Variable Speed 1023082
