Comfort Plus Appendix n A.04
Appendix
PARTS LIST - 3100 SERIES
* Optional voltages are available. Contact factory with model number and serial
number of the system for information.
When ordering parts, please include the system model and serial numbers.
DWG.
REF.
NO.
DESCRIPTION
3120
ITEM NO.
1 Front Painted Panel, Right Side 5940728
2 Electrical Panel Cover 5940794
3 Front Galvanized Panel 5940770
4 Standoffs, Front 5940774
5 Core Blower 1021001R
6 Heating Elements *
7 Blower Access Cover 5940796
8 Supply Air Blower Support Bracket 5940702
9 Base Temperature Limit Switch 1012008R
10 Base Temperature Limit Mounting Bracket 5940711
11 Front Air Channel 5940779
12 Brick 5903015
13 Low Voltage Panel 5940748
14 Terminal Block 12 Position 1016040
15 Terminal Block 6 Position 1016041
16 Supply Air Blower Assembly (PSC) 1041630
" Supply Air Blower Assembly (Variable Speed)
1041631
17 Supply Air Blower 1/2 HP 1075 RPM (PSC) 1040086
" Supply Air Blower 1/3 HP 850 RPM (PSC) 1040090
" Supply Air Blower 1/2 HP (Variable Speed) 1020007R
18 Supply Air Blower Capacitor 1018006R
19 Supply Air Blower Mounting Bracket 5940704
20 Breaker Standoff 5940766
21 Processor Control Board Mounting Bracket 5940746
22 PCB Processor Control Board 1023065R
23 PCB Base I/O Relay Board 1023078R
24 PCB Relay Expansion 1023067R
25 Right Front Base Painted Panel 5940764
26 Back & Left Side Base Painted Panel 5940762
27 Upper Left Side Painted Panel 5940780
28 Top Painted Panel 5940768
29 Insulation Blanket Inner 1054110
" Insulation Blanket Outer 1054115
30 Core Limit Switch 320D 1012011R
