Appendix
PARTS LIST - 4100 SERIES CONTINUED
Comfort Plus Appendix n A.08
DWG.
REF.
NO.
DESCRIPTION
4120
ITEM NO.
4130
ITEM NO.
4140
ITEM NO.
38 Left Side Front Base Panel 5940580 5940580 5940580
39 Bottom Panel 5940568 5940568 5940568
40 Base Top Panel 5940566 5940566 5940566
41 Base Deflector Panel 5940502 5940502 5940502
42 Back Bottom Base Painted Panel 5940582 5940582 5940582
43 Left Side Bottom Painted Panel 5940594 5940594 5940594
44 Left Side Back Painted Panel 5940599 5940530 5940598
45 Core Limit Switch 290D 1012019R 1012019R 1012019R
46 Limit Zone Painted Cover 5940585 5940527 5940591
47 Left Side Top Painted Panel 5940584 5940584 5940584
48 Left Side Core Panel 5940561 5940565 5940560
49 Insulation Blanket Inner 1054130 1054134 1054140
50 Insulation Blanket Outer 1054132 1054136 1054142
51 Back Painted Panel 5940593 5940528 5940592
52 Galvanized Core Panel Back 5940563 5940567 5940562
53 Galvanized Core Panel Top 5940564 5940564 5940564
54 Core Blower Limit Switch 170D 1012009 1012009 1012009
55 Discharge Air Sensor 1041536R 1041536R 1041536R
56 Supply Air Blower Limit Switch 190D 1012026R 1012026R 1012026R
57 Supply Air Blower Wiring Harness 1011701 1011701 1011701
58 PSC Motors with capacitor
" Supply Air Blower 1/2 HP 1075 RPM 1040086 1040086 1040086
" Supply Air Blower 3/4 HP 1075 RPM 1040091 1040091 1040091
" Variable Speed Motors
" Supply Air Blower 1/2 HP (Variable Speed) 1020007R 1020007R 1020007R
" Supply Air Blower 1 HP (Variable Speed) 1020008R 1020008R 1020008R
59 Supply Air Blower Capacitor 1018006R 1018006R 1018006R
60 Plenum Assembly 1022009 1022009 1022009
61 Blower Wheel 1021000 1021000 1021000
62 Terminal Block 6 Position 1016041 1016041 1016041
63 Electrical Panel, Main Body 5940556 5940556 5940556
64 Electrical Panel, Bottom 5940554 5940554 5940554
65 Interface Cable, 18" 1010014R 1010014R 1010014R
66 Interface Cable, 12" 1010012R 1010012R 1010012R
67 Faceplate Label 1159029 1159029 1159029
68 Time Clock Module (optional) 1301014 1301014 1301014
69 PCB ECM Motor Interface Variable Speed 1023082 1023082 1023082
70 Harness Motor ECM Low Voltage 1011703 1011703 1011703
71 Harness Line Voltage Variable Speed 1011702 1011702 1011702
72 Harness Process Output Variable Speed 9 Pin 1011705 1011705 1011705
73 Harness Process Input Variable Speed 15 Pin 1011704 1011704 1011704

When ordering parts, please include the system model and serial numbers.
