Steinbach Classic 310 - Connecting the Pressure Line; Connecting the Suction Line

3. Aach a hose with a 32 mm diameter
to the "RETURN" connecon and
fasten it with a hose clamp.
Screw the oponal adapter for INTEX
pools/Steinbach 2" ext. thread x 1" int.
thread
36
onto the return line
29
on
the valve head
1
by turning
clockwise.
Slide a hose with a 38 mm diameter
over the thread up to the stop of the
"RETURN" connecon and fasten it with a hose clamp.
4. Connect the second end to the connecon on the injecon nozzle of the pool.
The return line
29
is connected.
Connecting the pressure line
1. Push one end of the pressure hose
14
onto the pump outlet
28
.
2. Place a hose clamp
15
over the
pressure hose. Using a Phillips
screwdriver PH1
34
, turn the screw on
the hose clamp clockwise to ghten
the hose clamp over the connecon.
3. Place the second hose clamp over the
pressure hose.
4. Push the end of the pressure hose
onto the pressure line
3
connecon
on the valve head
1
.
5. Posion the hose clamp on the
connecon and ghten this one as
well with a Phillips screwdriver.
The pressure line
3
is connected.
Connecting the suction line
Connecting the suction line with the self-fastening hose
- When using self-fastening hoses Ø 32 / 38 mm.
15
1
29
16
14
15
28
17
1
27
