Steinbach Straight Line - Solar Shower Assembly

shower head should point downwards. If screw connections are not water-tight, wrap the thread in
Teflon tape.
To assemble the solar shower, proceed as follows:
2
2
3
1
3
1. Place the O-ring
1
on the connecting element
2
and screw the connecting element into the
tank
3
.
2. Assemble the shower head
10
.
4
2
10
11
5
6
5
7
3. Place the O-ring
11
on the connecting element
2
and screw the shower head
10
onto the
connecting element.
4. Screw the hose adapter
7
onto the hose connection.
5. Place the O-ring
5
on the drain cap
6
and screw the drain cap into the tank.
6
3
8
9
6. Place the O-ring
9
on the cold water outlet
8
and screw the cold water outlet into the tank.
The solar shower is assembled.
