USER’S GUIDE
PLATFORM SCALES
1. INTRODUCTION
The Steinberg Series of electronic price scale are equipped with high precision
load cell as primary instrument, the secondary instrument designed by using new
technology and new materials such as 8951 single-chip microprocessor as main
chip and A/D converted with three-integral or Σ-Δ module conversion.
The Steinberg Systems series of electronic price scale are good products with
reasonable prices. It has functions of overload and under-voltage alarms, auto
and continuous AC/DC shift, power supply identication, price or weight adding
which is according to model. Particularly, it can protect the saved data to ensure
accurate weighing.
2. MEASURING PERFORMANCE
2.1 Accuracy
2.1.1 Class III
2.1.2 Precision: 1/3000F•S~1/30000F•S (according to scales’ model)
2.2 Indexes of interval number (n) display, verication interval, maximum capa-
city, minimum capacity, zero set range, tare range, zero tracking range and limit
display (overload alarm) are shown in the following table:
Model SBS-PF-100A1 / SBS-PF-100A8
SBS-PF-100A8 foldable
SBS-PF-
A150/20
SBS-BW-
1T/60*80
SBS-
PF-600/100
Interval number (n) 5000 3000 2000 3000
Verication interval (e) 10g 50g 500g 200g
Maximal capacity (max) 100kg 150kg 1000kg 600kg
Minimal capacity (min) 400g 1000g 10kg 4kg
Zero range 0~1200g 0~3000g 0~30kg 0~12kg
Tare range (max) 0~100kg 0~150kg 0~1000kg 0~600kg
Zero tracking range 0~10g 0~25g 0~250g 0~100g
Limit display 100,18kg 150.45kg 1004.5kg 601.8kg
Note: e = d
2.3 Error range
Weight
(described as e)
Error range
Outgoing inspection Inspection after repair
0≤m≤500e ±0.5e ±1.0e
500e<m≤2000e ±1.0e ±2.0e
2000e<m≤3000e ±1.5e ±3.0e
Note: e is verication interval
3. ELECTRICAL CHARACTERISTICS
3.1 Alternating current characteristics:
3.1.1 Working voltage: 230V (+10%~-15%);
3.1.2 Power frequency: 50+2%Hz
17
