Steinberg SBS-LW-7500A - Technical Details; Max. Capacity; Scaling of Measurement (d); Standard (e)

USER MANUAL
PRECISION SCALE
EN
Display
Level bubble
Weighing plate of stainless steel
Power cable plug
Plastic feet
Model SBS-LW-7500A SBS-LW-10000A
Max. capacity 7500g 10000g
Scaling of measurement (d) d = 0.1g
Standard (e) e = 10d
Accuracy class III
Ambient temperature 0-40 °C
Energy Consumption DC 7,5V Adapter; 4 batterien R6 AA (54mA)
1. TECHNICAL DETAILS
II. FUNCTIONS OF THE KEYS
1. ON/OFF
Press the ON / OFF button to start the unit. Hold the button pressed for 3 seconds
to turn off the scale.
2. UNIT
The unit change is possible by pressing the MODE button. Then press up to reach the
desired unit.
There are 13 units (g / ct / lb / oz / dr / gn / ozt / dwt / MM / tl.J / tl.T / tl.H / t).
9
EN
