09-282C 6 - 3 rev 5/00
PARTS section 6
Parts List for Figure 1
Ref Part no. Description Quantity
1 83-2TB124 Pulley, 2-groove 12-3/4 diameter 1
2 81-B054 Belt, B54 2
3 83-Q124 Bushing, Q1 x 1-1/2 1
4 85-K0612 Key, 3/8 x 1-1/2 1
5 99-K26 Flange Bolt, 1/4 x 3/4 5
6 00-093 Decal, Warning Read Owner's Manual 1
7 60-576 Shield, Belt 1
8 92-08 Nut, 1/2 5
9 96-08 Lock Washer, 1/2 5
10 90-0810 Bolt, 1/2 x 1-1/4 4
11 02-PP0524 Presto Pin, 5/32 x 2-15/16 1
12 99-F36 Bolt, Special 1/2 x 1-1/2 1
13 62-757 Hitch Frame 1
14 99-E20 Flange Nut, 1/4 1
15 90-0822 Bolt, 1/2 X 2-3/4 1
16 80-244 Drive Shaft 1
17 55-FB23016 Flange Bearing, 2 Bolt, 1" 2
18 90-0610 Bolt, 3/8 X 1-1/4 4
19 83-BK52H Pulley 1
20 83-H16 Bushing, 1" 2
21 85-K0410 Key, 1/4 X 1-1/4 2
22 62-758 Support Stand 1
23 99-E12 Flange Nut, 5/16 5
24 99-K19 Bolt, Flange 5/16 x 3/4 1
25 83-028 Flat Idler 1
26 99-K02 Bolt, Flange 5/16 X 1 4
27 96-06 Lock Washer, 3/8 6
28 92-06 Nut, 3/8 7
29 83-2BK50H Pulley 1
30 60-575 Shield, Drive Pulley 1
31 00-025 Decal, Warning Keep Hands Away 1
32 41-010 Spring, 5" 1
33 90-0612 Bolt, 3/8 X 1-1/2 1
34 99-A06 Locknut, 3/8 1
35 95-08 Flat Washer, 1/2 SAE 2
36 99-A08 Locknut, 1/2 Stover 1
37 40-300 Idler Arm 1
38 95-06 Flat Washer, 3/8 SAE 2 or A/R
39 90-0622 Bolt, 3/8 x 2-3/4 1
* 81-B041 Drive Belt, B41 1
* 30-004B Terminal, Female Spd. 1
* Not Illustrated
