09-282C 6 - 7 rev 8/98
PARTS section 6
Parts List for Figure 3
Ref Part no. Description Quantity
1 31-020A Knob, Black for 31-020 1
2 99-K26 Flange Bolt, 1/4 x 3/4 2
3 99-E20 Flange Nut, 1/4 6
4 64-731 Safety Switch Bracket 1
5 00-154 Decal, Emergency Stop 1
6 31-020 Switch, Push-Pull 1
7 11-016 Wire Clip, 13/32 2
8 30-173 Cable, 3-wire Switch to Plug - 60" 1
9 30-163 Connector Plug, 4 pole 1
10 30-164 Connector Socket, 4 pole 1
11 64-733 Mounting Bracket, Electrical Socket 1
12 30-174 Wiring Harness, All Model 420 & 425 w/o electric clutch 1
30-175 Wiring Harness, Model 425 with electric clutch 1
30-187 Wiring Harness, Model 525 with electric clutch 1
13 30-112 Connector, for 35-067 1
14 35-067 Relay 1
15 99-K31 Flange Bolt, 1/4 x 1/2 4
