09-282C 6 - 9 rev 8/02
PARTS section 6
MODEL CS313
Parts List for Figure 4
Ref Part no. Description Quantity
1 87-CS70521 Hinge Pin, 5/16 x 14" 1
2 95-05 Flat Washer, 5/16 SAE 9
3 87-CS15356 Locknut, 5/16 NYL 11
4 87-CS70471 Impeller 1
5 87-CS70604 Shaft, Blower 1
6 90-0516 Bolt, 5/16 x 2 1
7 87-CS70586 Housing, Blower 1
8 87-CS17960 Clamp, 4-1/4" ID 1
9 87-CS70249 Blower Tube 1
10 97-0506 Carriage Bolt, 5/16 x 3/4 2
11 87-CS70253 Spout, Blower Tube 1
12 87-CS15321 Knob 1
13 90-0508 Bolt, 5/16 X 1 1
14 90-0506 Bolt, 5/16 X 3/4 10
15 00-002 Decal, Steiner Small 1
16 00-138 Decal, Danger-Rotating Blades 1
17 87-CS15402 Speed Nut, 5/16 4
18 87-CS17692 Spring, Extension 3/4" OD 1
19 87-CS69126 Spacer, Idler Pivot 1
20 87-CS15060 Carriage Bolt, 3/8 x 2 1
21 87-CS70475 Idler Plate, Blower 1
22 87-CS17740 Pulley, Idler 3-1/2" 1
23 87-CS15388 Locknut, 3/8 NYL 1
24 87-CS17831 Bearing, 1" Flushmount, 3 Bolt 2
25 87-CS15391 Key, Square 1/4 x 2" 1
26 87-CS17958 Pulley, Cast 1" Bore, 4" OD 1
27 87-CS70602 Belt Guard 1
28 87-CS16086 V-Belt, BX49 1
29 87-CS16016 Bushing, 1-1/2 1
30 87-CS16499
Pulley, 3.6 x 1B-SH
1
31 87-CS15441 Key, 3/8 x 1/4 x 2" 1
32 99-AC08 Locknut, 1/2 1
33 87-CS70496 Bracket, Belt Guard 1
34 00-093 Decal, Warning Read Owner’s Manual 1
