2.3 DESCRIPTION OF MAJOR COMPONENTS
ITEM DESCRIPTION
1 Tape Fastener Loop 5/8" (Black)
2 Tape Fastener Hook 1/2" (attached to remote cable switch) (Black)
3 Remote Cable Switch, 7"
4 Optical Instrument Reticle (OIR) (set of 5)
5 Battery, 3V CR 123A (must be used with associated battery cap)
6 DBAL-I
2
Assembly
7 Plastic Case
8 Operator and Field Maintenance Manual
Fig. 2-2 DBAL-I
2
Major Components
15
