Steiner MD460 Owner/Operator's Manual & Illustrated Parts List

rev 9/00 6 - 14 09-254B
PARTS section 6
Hitch and
Drive Parts
Figure 3
Parts List for Figure 3
Ref Part No. Description Quantity
1 85-K0310 Key, Sq. 3/16 X 3/16 X 1-1/4 2
2 92-08 Nut, 1/2 (See Note 3) 2
99-E37 Flange Nut, 1/2 (See Note 4) 2
3 81-A128 Belt (Model MD448) 1
81-A158 Belt (Model MD460) 1
81-B180 Belt (Model MD472) 1
4 83-BK5012 Pulley, 5", 3/4" Bore 1
5 99-K13 Bolt, Flange 3/8 X 1 4
6 99-E13 Flange Nut, 3/8 16 A/R
See Note 4

Steiner MD460 Specifications

General

Brand	Steiner
Model	MD460
Category	Lawn Mower
Language	English
