15
ROTARY
MOWER
TO REMOVE BELT:
Serial Numbers:
75-70855 1001-1493
75-70860 1001-4727
75-70865 1001-1969
Remove top shield and the bolts which fasten the hitch arms to the deck brackets. No further disassembly
is necessary.
Serial Numbers:
75-70855 1494 & Up
75-70860 4728 & Up
75-70865 1970 & Up
Remove the six 1/4" X 3/4" bolts from the flip-up braces and remove the pivot stop pin and the idler spring.
Remove the braces.
• With the idler spring released, move the idler toward the drive shaft.
• Slip belt off the outer spindle pulleys.
• Slip belt off the front center idler and spindle.
• Remove belt.
SERVICE
