35
ROTARY
MOWER
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
FLIP-UP DECKS
FIGURE 9
9-1 REF MAIN DECK WELDMENT 1
9-2 40-329.7 IDLER ARM-(48" & 60") 1
40-330.7 IDLER ARM-(72") 1
9-3 64141-2 NUT-WLF 1/4-20 10
9-4 6107645 CHAIN, IDLER ARM STOP 1
9-5 64123-80 BLT-HEX 1/4-20X1-1/4 1
9-6 41-092 SPRING-(60") 1
41-052 SPRING-(48") 1
41-051 SPRING-(72") 1
9-7 64-966 PIVOT STOP PIN 1
9-8 64025-09 HEX, NUT 1/2-13 2
9-9 64006-05 LOCKWSHR-HELICAL 1/2 2
9-10 F1002 NUT, JAM 1/4-20 1
9-11 83-012 IDLER-"V" 1/2" ID X 4-1/2" OD 2
9-12 90-0814 BOLT-1/2 X 1-3/4 1
9-13 64123-50 BOLT-HEX 3/8-16X1 2
9-14 64-799 WASHER-13/32IDX1-9/32OD 2
9-15 85-B29 BUSHING-.406X.740X.258 1
9-16 83-034 IDLER-"V" 3/8" ID X 5" OD 1
(USED ON 72" ONLY)
9-17 64163-61 WSHR .81X.406X16GA 3
(USED ON 72" ONLY)
9-18 64-967.7 FLIP-UP LATCH 1
9-19 41-013 SPRING-EXT. 0.50 X 1.938 1
9-20 64-965.7 FRONT LIFT ARM STOP 1
9-21 64229-03 LOCKNUT-NYLON 3/8-16 1
9-22 64139-04 BOLT-WLF 1/4-20X3/4 8
9-23 64-968.7 FLIP-UP DECK BRACE-LFT 1
(USED ON 60" & 72" ONLY)
64-970.7 FLIP-UP DECK BRACE-LFT 1
(USED ON 48" ONLY)
9-24 64-969.7 FLIP-UP DECK BRACE-RT 1
(USED ON 60" & 72" ONLY)
64-971.7 FLIP-UP DECK BRACE-RT 1
(USED ON 48" ONLY)
9-25 64168-1 COTTER-HAIRPIN.120X2-3/8 1
9-26 62-858.7 ARM, RIGHT HITCH 1
9-27 64-998.7 HOLD DOWN-RLR FRAME 1
(USED ON 72" SN 2592 - )
9-28 64141-4 NUT-WLF 3/8-16 2
9-29 64-939.7 ANCHOR, LIFT ARM LEFT 2
64-938.7 ANCHOR, LIFT ARM RIGHT 2
9-30 64229-05 LOCKNUT, 1/2-13 1
9-31 64163-67 WASHER-.516X1X12 4
9-32 64123-125 BOLT-HEX 1/2-13X2-3/4 1
9-33 64123-87 BOLT-HEX 3/8-16X1-3/4 1
9-34 64139-21 BLT-WLF 3/8-16X3/4 2
(USED ON 72" SN 2592 - )
