ROTARY
MOWER
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
DECK PARTS 48"
FIGURE 1
1-1 47-050 KNOB 4
64002-04 LOCKWASHER, EXT. 5/16 4
(SN 1001 - 1433)
1-2 60-535 SHIELD-TOP 1
(SN 1001 - 1009)
60-567 SHIELD-TOP DECK 1
(SN 1010 - 1433)
60-652 SHIELD-TOP DECK 1
(SN 1434 - )
1-3 41-052 SPRING-EXT 0.875 X 6.750 1
1-4 6107645 CHAIN, IDLER ARM STOP 1
(SN 1001 - 1577)
1-5 64-534 HOOK-SPRING 1
(SN 1001 - 1577)
1-6 64141-2 NUT-WLF 1/4-20 4
1-7 29-010 GREASE FITTING-1/4 3
1-8 64164-12 KEY-1/4X1/4X1 SQ END 3
1-9 83-H16SPL BUSHING-H X 1" SPLIT TYPE3
1-10 83-BK50H PULLEY-5" H1 BUSHING 3
1-11 64123-117 BOLT-HEX 1/2-13X1-1/2 1
1-12 83-012 IDLER-"V" 1/2" ID X 4-1/2" OD 2
1-13 99-B12 WASHER-1/4 X 17/32 X 1-1/8 2
1-14 62-723 DECK-TOP 1
(SN 1001 - 1433)
62-843 DECK-TOP 1
(SN 1434 - 1577)
62-872 UPR DK WLDMT 1
(SN 1578 - )
1-15 64025-09 HEX, NUT 1/2-13 2
1-16 64006-05 LOCKWSHR-HELICAL 1/2 2
1-17 64163-67 WASHER-.516X1X12GA 1
1-18 85-B29 BUSHING-.406 X .740 X .258 1
1-19 90-0814 BOLT-1/2 X 1-3/4 1
1-20 40-290 IDLER ARM 1
(SN 1001 - 1577)
40-329.7 IDLER ARM 1
(SN 1578 - )
1-21 64141-4 NUT-WLF 3/8-16 18
1-22 64139-18 BLT-WLF 3/8-16X1-1/4 12
1-23 64139-21 BLT-WLF 3/8-16X3/4 5
1-24 62-716 DECK-MOWER 1
(SN 1001 - 1433)
62-844 DECK-MOWER 1
(SN 1434 - )
1-25 60-534 CHUTE-SIDE DISCHARGE 1
1-26 87-143 SPINDLE 3
1-27 79-062 BLADE-16-1/4" .700 AIR LIFT 3
79-064 BLADE-16-1/4" 1-3/8 AIR LIFT3
(OPTIONAL)
1-28 99-B14 WASHER-1/4 X 1/2 ID X 3 OD 3
1-29 91-0810 BOLT-1/2 X 1-1/4 NF 3
1-30 64123-50 BOLT-HEX 3/8-16X1 1
1-31 64-799 WASHER-13/32 X 1-9/32 1
1-32 99-K38 BOLT-1/4 X 1-1/4 BH 2
(SN 1010 - )
1-33 64163-03 WSHR-.256IDX.62ODX18 2
(SN 1010 - )
1-34 64-687.7 SPACER 2
(SN 1010 - )
1-35 00-137 DECAL-SPIRAL INDICATOR 1
(SN 1010 - )
60-568 SUPPORT 1
(SN 1010 - )
1-36 56-059-17 TRIM-LOC-RUBBER 17" 1
(SN 1010 - )
1-37 06-010 CAP PLUG-1" 1
(SN 1010 - )
1-38 64-866 SHIM-SPINDLE 22 GA. 1
(1 PAIR OPTIONAL)
64-867 SHIM-SPINDLE 16 GA. 1
(1 PAIR OPTIONAL)
64-868 SHIM-SPINDLE 12 GA. 1
(1 PAIR OPTIONAL)
1-39 47-090 LATCH-RUBBER 3" LONG 3
(SN 1434 - )
1-40 04-008 POP RIVET-1/8 X 1/4 SS 6
(SN 1434 - )
1-41 04-007 POP RIVET-1/8 X 1/8 SS 6
(SN 1434 - )
1-42 64-900.7 BRKT-TOP SHIELD LATCH 1
(SN 1434 - )
1-43 64139-02 BLT-WLF 1/4-20X1/2 2
(SN 1434 - )
1-44 64123-15 BOLT-3/8-16X3/4 3
1-45 64025-05 NUT-3/8-16 3
1-46 64006-03 LOCKWASHER-3/8 3
1-47 00-092 DECAL-HANDS & FEET 2
1-48 00-139 DECAL-WARNING 2
1-49 00-138 DECAL-DANGER 1
1-50 00-129 DECAL-BELT INSTALL 1
(LOCATED UNDERNEATH TOP SHIELD)
1-51 4128363 DECAL-STEINER LOGO 1
1-52 00-140 DECAL-ANSI CERT. 1
1-53* 00-093 DECAL 1
1-54* 4112761 LABEL-MADE IN USA 1
* NOT ILLUSTRATED
