Steiner MD460 User Manual

29
ROTARY
MOWER
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
FIGURE 6
FRAME PARTS 72"
6-1 64141-4 NUT-WLF 3/8-16 10
6-2 03-0610 CLEVIS PIN-3/8 X 1-1/4 1
6-3 02-PP0318 PRESTO PIN-3/32 X 2-5/16 1
6-4 29-010 GREASE FITTING-1/4 2
6-5 62-731.7 FRAME-TUBE 1
6-6 99-K75 BOLT-HEX 3/8-16X1-1/2 4
6-7 53-060 HUB CAP-FOR MOWER 2
6-8 99-AC12NFLOCKNUT-CENTER 3/4 NF 2
6-9 64163-06 WASHER-.768/.756X1.25X14 12
6-10 55-Z9504AB BALL BEARING-3/4 ID 4
6-11 64-807.7 SPACER 2
(SN 1001 - 3246)
64-845.7 SHIELD-BEARING 2
(SN 3247 - )
6-12 4132783.7 CASTER, MOWER 2
6-13 90-0640 BLT-HEX 3/8-16X5 2
6-14 53-104 WHEEL-10.25 X 3.25 2
(SN 1001 - 2882)
55-G527 BEARING-BALL 2
55-107 BEARING-5/8 ID X 1-3/8 OD 2
(OPT HD)
53-186 WHEEL-10.25 X 3.25 2
(SN 2883 - )
55-112 BRG-ROLLER 5/8IDX1-3/8 1
53-187 RETAINER-FLANGED 2
6-15 64163-16 WASHER-41/64X1, 3/8X12GA12
6-16 50-062 AXLE TUBE-CASTER WHL 2
6-17 64-799 WASHER-13/32 X 1-9/32 18
6-18 42-444.7 LINK-MIDDLE RIGHT 1
6-19 64123-87 BOLT-HEX 3/8-16X1-3/4 1
6-20 64229-05 LOCKNUT, 1/2-13 NYLON 3
6-21 42-449.7 LINK-HEIGHT ADJT FRT LFT 1
6-22 42-452.7 LINK-HEIGHT SELECTOR 1
6-23 64123-117 BOLT-HEX 1/2-13X1-1/2 1
6-24 90-0832 BOLT-1/2 X 4 2
6-25 64163-67 WASHER-.516X1X12GA 2
6-26 42-451.7 LINK-MID LIFT 1
6-27 62-732 FRAME-ROLLER 1
(SN 1001 - 2301)
62-871.7 FRAME-REAR ROLLER 1
(SN 2302 - )
6-28 50-080.7 ROLLER-REAR 1
6-29 50-105 ROLLER-FRONT 1
85-B11 BEARING-3/4" WOOD RLR 2
6-30 50-074 AXLE-ANTI SCALP ROLLER 1
6-31 64123-219 BOLT-HEX 3/8-16X6 1
6-32 64141-6 NUT, 5/16-18 4
6-33 55-FB16016 BEARING-160 FLANGE 1" 2
6-34 64018-15 BLT-CRG 5/16-18X1 4
(SN 1001 - 1285)
64123-47 BLT-HEX 5/16-18X1-1/4 4
(SN 1286 - 2301)
99-K62 BOLT-FLANGE 5/16 X 1-1/4 4
(SN 2302 - )
6-35 64-663 BUSHING-ADJ LINK THIN 6
6-36 64123-87 BOLT-HEX 3/8-16X1-3/4 1
6-37 29-045 GREASE FITTING-1/4 45 1
6-38 64-662 BUSHING-ADJ LINK THICK 2
(SN 1195 - )
6-39 64139-21 BLT-WLF 3/8-16X3/4 1
