Stel THOR 40H - Control Panel Diagram and Machine Specifications; Control Panel Diagram; Electrical Characteristics; Mechanical Characteristics

102
THOR 40/60 H
COD. 6983000010
STEL s.r.l. – Via del Progresso n° 59 – 36020
Loc. Castegnero (VICENZA) - ITALY
TEL. +39 444 639525 (central.) – +39 444 639682 (comm.)
FAX +39 444 639641 – E-mail: stel @ stelgroup.it
http: www.stelgroup.it
FIGURES
Fig. 1
FRANÇAIS
THOR 40/60 H
COD. 6983000010
47
STEL s.r.l. – Via del Progresso n° 59 – 36020
Loc. Castegnero (VICENZA) - ITALY
TEL. +39 444 639525 (central.) – +39 444 639682 (comm.)
FAX +39 444 639641 – E-mail: stel @ stelgroup.it
http: www.stelgroup.it
TAB.1 (Technical data)
N.B.) DEGREE OF PROTECTION IP22
The machine casing guarantees:
1) Protection against direct contact of a finger with dangerous parts.
2) Protection against the penetration of foreign bodies with O > 12.5 mm.
3) Protection against the vertical falling of drops of water with a maximum
casing inclination of 15°.
TECHNICAL DESCRIPTION
ELECTRICAL CHARACTERISTICS
ENGLISH
MECHANICAL CHARACTERISTICS
GENERATOR
UNIT
THOR 60H 3F
Cod. 6008300000
220/230
3
50/60
7
11,5
10,5
17
30÷60
40
60
300
220/230
1
50/60
6.5
11
29
50
30÷55
40
55
300
220/230
1
50/60
4.6
6.4
20
27
25÷40
30
40
300
V
Hz
KVA
KVA
A
A
A
A
A
V
SUPPLY VOLTAGE
PHASES
FREQUENCY
RATED POWER ED 100%
RATED POWER ED 60%
RATED CURRENT ED 100%
RATED CURRENT ED 60%
REGULATION RANGE
CUTTING CURRENT ED 100%
CUTTING CURRENT ED 60%
NO LOAD VOLTAGE
THOR 60H 1F
Cod. 6024900000
THOR 40H 1F
Cod. 6003400000
GENERATOR
UNIT
THOR 60H 3F
Cod. 6008300000
22
EN 50192
40
18
403
203
290
18
22
EN 50192
40
17,5
403
203
290
18
22
EN 50192
40
12
403
203
290
17
IP
C°
mm
mm
mm
mm
Kg
DEGREE OF PROTECTION
STANDARD
WORKING TEMPERATURE
MAXIMUM CUTTING THICKNESS
LENGTH
WIDTH
HEIGHT
WEIGHT
THOR 60H 1F
Cod. 6024900000
THOR 40H 1F
Cod. 6003400000
