stellar labs V480 - Cylinder Group

10 Class 4 Compressor Owner’s Manual
Cylinder Group
6
5
4
2
3
5
12
9
8
7
10
11
1
12
.YTQNOITPIRCSEDTRAPMETI
2TEKSAG REDN
I
LYC
7
400C1
2C6364 CONNECTING ROD 200/V480 O/S 2
2084V/002 NOTSIP76753
208
4
V/002 N
I
P NOTS
I
P7636C4
5C6273 SNAP RING PISTON PIN N5000-62 4
6C6360 CYLINDER V480 FINISHED O/S 1
6KCOL 13.0 REHSAW22507
8C0922 CAP SCR 0.31-18X1.00 HHGR5 6
95827 RING OIL V480/200 FLEX DIVIDER 2
10 32931 RING SCRAPER V480/200 H#48638 2
11 32930 RING CPRSN V480/200 BARREL H#38347 2
12 36368 RING OIL V480/200 RING RAIL 4
CYLINDER GROUP
