2 Class 4 Compressor Owner’s Manual
Specifications
• Model: V480
• Weight: 87 lbs (SHD-60: 175 lbs)
• Displacement @ 1200 RPM: 44 CFM
• Delivery: 28 CFM @ 100 PSI
• Maximum Working Pressure: 155 PSI
• Oil Capacity:
1 Quart
• Cylinders: Four Cylinder(Single Stage)
• Pressure switch presets: Engage - 115 PSI
Disengage - 150 PSI
• 10 GPM Hydraulic System • 1800 PSI System Pressure
• 2500 PSI Pressure Relief Setting • 12 VDC Solenoid Control Valve
• All Steel Plumbing W/ JIC Fittings • 165 Sq. In., 300 BTU Cooler
• 361 CFM, 12 Volt Cooler Fan • 6061 Aluminum Manifold
• Direct Drive Coupling • Air Pressure Control Valve
SHD-60 Drive System Description
• Cast Iron Crankcase Casting • Heavy Ductile Iron Crankshaft
• Cast Aluminum Cylinder Head • Micro-honed Connecting Rods
• High Temperature Precision Pistons • Tapered Roller Bearings
• Stainless Steel Reed Valves • Pressure Lubricated System
• Heavy Duty Journal Bushings • Oil Pressure Gauge
• Pulsation Manifold
Compressor System Description
General Specifications
