STEMME S10 Service Manual

Maintenance Manual STEMME S10 Date of Issue Oct. 1, 1990 page: 51
Amendment No.: 19 Date: Jan. 10, 2014
A4010021_B19.doc Doc.No.: A40-10-021
9. Equipment
9.1 Minimum Equipment List
Subject Manufacturer Type
TC No., Specification
No.
Range
Airspeed Indicator Winter 6FMS4 TS10.210/15 up to 300 km/h/
180 mph / 160 kts
Winter 6FMS5 TS10.210/16
Winter 7FMS4 TS10.210/19
Winter 7FMS5 TS10.210/20
Altimeter Winter 4FGH10 TS10.220/46 up to 10,000 m/
30,000 ft
Winter 4FGH20 TS10.220/47
Winter 4FGH40 TS10.220/48 up to 20,000 ft
Winter 4HM6 TS10.220/44 up to 6,000 m
up to 20,000 ft
PZL W-12S FD-3/75
Compass Airpath C2300 - -
PZL B-13 FD19/77 -
Ludolph FK16 10.410/3 -
Ludolph FK5 10.410/1 -
Hamilton HI400 TSO C7c Type 1 -
Presesion Aviation
Inc.
PAI-700 TSO
Stall Warning
System
Westerboer Speed Control - -
Revolution Counter VDO 333.230/009/1 - up to 4000 min
-1
Engine hour meter Winter FSZM TS-GW 1510 -
VDO 331.811/010/2 - -
Oil pressure meter VDO 350.271/031/7 - up to 10 bar
Oil temp. meter VDO 310.274/082/1 - up to 150 °C
Fuel contents meter
VDO 301.271/036/1 - 0 ···
4
/
4
Cylinder head
temperature meter
Limbach 170.215/001 - up to 375 °C
Four-element straps
Gadringer BaGu 5203
SchuGu 2700
40.070/32
40.071/05
Schroth Automatic Shoulder
belt, left
Automatic Shoulder
belt, right
SL/1-08-C702
(with stop)
SR/1-08-C702
(with stop)
Back-cushion One per seat, compressed 2 in. (50 mm) thick
(if no parachute, minimum 2 in. thick, is used)
