15.1 MODEL: STERLING S400
ISO 7176-15 MIN. MAX. COMMENTS
OVERALL LENGTH 1345mm 1345mm STANDARD CONFIGURATION
OVERALL WIDTH 645mm 645mm STANDARD CONFIGURATION
TOTAL MASS (WITH BATTERIES) 108.5kg 108.5kg STANDARD CONFIGURATION
MASS OF THE HEAVIEST PART - 35kg SEAT
STATIC STABILITY DOWNHILL - 8° 136KG USER
STATIC STABILITY UPHILL - 8° 136KG USER
STATIC STABILITY SIDEWAYS - 8° 136KG USER
ENERGY CONSUMPTION (MAX. RANGE) - 25 km TO ISO 7176-4 (SEE SECTION 9.13)
DYNAMIC STABILITY UPHILL - 8°-18% 136KG USER
OBSTACLE CLIMBING - 50mm STANDARD CONFIGURATION
RAMP TRANSITION 8° 8° WITHOUT HIGH CENTRING
MAX. SPEED FORWARD 6 kph/ 4 mph STANDARD CONFIGURATION
MIN. BRAKE DISTANCE FROM MAX. SPEED - 4m WITH STANDARD PROGRAMMING
MAX. SPEED REVERSE - 50% % OF FORWARDS SPEED
EFFECTIVE SEAT DEPTH 460mm STANDARD CONFIGURATION
EFFECTIVE SEAT WIDTH 460mm STANDARD CONFIGURATION
SEAT SURFACE HEIGHT 447mm 497mm TO SCOOTER FLOOR (3 POSITIONS)
BACK REST ANGLE -70° 60° FROM VERTICAL
BACK REST HEIGHT 525mm STANDARD CONFIGURATION
FORE / AFT SEAT ADJUSTMENT +100mm FROM REAR MOST POSITION
SEAT WEIGHT WITH SLIDE 35kg STANDARD CONFIGURATION
TOP OF ARM REST TO SEAT 230mm ARM REST SET AT 90°
MIN. TURNING RADIUS 3.03m STANDARD CONFIGURATION
MIN. TURN BETWEEN WALLS 1.98m STANDARD CONFIGURATION
NOMINAL BATTERY VOLTAGE 24V 24V TWO 12V BATTERIES
REVERSING WIDTH 1.98m
ADDITIONAL SPECIFICATIONS MIN. MAX. COMMENTS
MAXIMUM POTENTIAL RANGE 36 KM INDUSTRY BENCHMARK (SECTION 9.15)
CONTROLLER CUT-OFF VOLTAGE 16V DRIVE STOPS
BATTERY CAPACITY 38Ah SEE OPTIONS
BATTERY FUSIBLE LINKS - 100A IN-LINE FUSE ON EACH BATTERY
BATTERY CHARGER LOOM FUSIBLE LINK - 15A
BATTERY CHARGER 5A 5A AUTOMATIC CYCLIC
MAX. KERB HEIGHT 50mm
GROUND CLEARANCE 45mm
REAR SUSPENSION TRAVEL 11mm UNLADEN
FRONT SUSPENSION TRAVEL 23mm UNLADEN
REAR WHEEL DRIVE - - 4 WHEEL SCOOTER
SCOOTER PUSH FORCE 100N IN FREE-WHEEL
CRASH TESTED NO
TYRE PRESSURE 40psi
