15.3 MODEL: STERLING S700
ISO 7176-15 MIN. MAX. COMMENTS
OVERALL LENGTH *1500mm *1500mm STANDARD CONFIGURATION
OVERALL WIDTH 657mm 657mm STANDARD CONFIGURATION
TOTAL MASS (WITH BATTERIES) 145.5kg 145.5kg STANDARD CONFIGURATION
MASS OF THE HEAVIEST PART - 35kg SEAT
STATIC STABILITY DOWNHILL - 10° 160KG USER
STATIC STABILITY UPHILL - 10° 160KG USER
STATIC STABILITY SIDEWAYS - 10° 160KG USER
ENERGY CONSUMPTION (MAX. RANGE) - 35 km TO ISO 7176-14 (SEE SECTION 9.13)
DYNAMIC STABILITY UPHILL - 10°-18% 160KG USER
OBSTACLE CLIMBING - 100mm STANDARD CONFIGURATION
RAMP TRANSITION 18° 18° WITHOUT HIGH CENTRING
MAX. SPEED FORWARD 15 kph STANDARD CONFIGURATION
MIN. BRAKE DISTANCE FROM MAX. SPEED - 6m WITH STANDARD PROGRAMMING
MAX. SPEED REVERSE - 50% % OF FORWARDS SPEED
EFFECTIVE SEAT DEPTH 490mm STANDARD CONFIGURATION
EFFECTIVE SEAT WIDTH 490mm STANDARD CONFIGURATION
SEAT SURFACE HEIGHT 450mm 500mm TO SCOOTER FLOOR (3 POSITIONS)
BACK REST ANGLE -70° 60° FROM VERTICAL
BACK REST HEIGHT 525mm STANDARD CONFIGURATION
FORE / AFT SEAT ADJUSTMENT +30mm FROM REAR MOST POSITION
SEAT WEIGHT WITH SLIDE 35kg STANDARD CONFIGURATION
TOP OF ARM REST TO SEAT 230mm ARM REST SET AT 90°
MIN. TURNING RADIUS 2950mm STANDARD CONFIGURATION
MIN. TURN BETWEEN WALLS 2250mm STANDARD CONFIGURATION
NOMINAL BATTERY VOLTAGE 24V 24V TWO 12V BATTERIES
REVERSING WIDTH 2250mm
ADDITIONAL SPECIFICATIONS MIN. MAX. COMMENTS
MAXIMUM POTENTIAL RANGE 55 km INDUSTRY BENCHMARK (SECTION 9.15)
CONTROLLER CUT-OFF VOLTAGE 16V DRIVE STOPS
BATTERY CAPACITY 75Ah SEE OPTIONS
BATTERY FUSIBLE LINKS - 100A IN-LINE FUSE ON EACH BATTERY
BATTERY CHARGER LOOM FUSIBLE LINK - 15A
BATTERY CHARGER 8A AUTOMATIC CYCLIC
MAX. KERB HEIGHT 100 mm
GROUND CLEARANCE 100 mm 130 mm
REAR SUSPENSION TRAVEL 50 mm UNLADEN
FRONT SUSPENSION TRAVEL 40 mm UNLADEN
REAR WHEEL DRIVE - - 4 WHEEL SCOOTER
SCOOTER PUSH FORCE 100N IN FREE-WHEEL
CRASH TESTED NO
TYRE PRESSURE 40psi
* Exceeds recomended dimensions.
