STERO, a division of Illinois Tool Works, Inc. 1758 Corporate Circle Petaluma, CA 94954
Phone: 800-762-7600 Fax: 707-762-5036 Website: Stero.com
ST50408 (10/15)
STERO SD3
Door-Type Dishwasher
MODEL:
SD3 ML-130232
INSTRUCTION
MANUAL

Table of Contents

Questions and Answers

  • C
    Christopher HallAug 14, 2025
    What to do if my STERO Dishwasher is not cleaning dishes properly?
    • A
      Andrew FranklinAug 14, 2025
      If your STERO Dishwasher isn't cleaning dishes well, several factors could be at play. Start by checking for any obstructions at the pump intake, as insufficient wash water due to a drain obstruction can prevent proper drain closing. Ensure wash and rinse arms rotate properly. Also, make sure dishes are scraped before starting the cycle. Deliming may be necessary if there are excessive mineral deposits throughout the wash and rinse system.
  • R
    Rebecca StewartAug 17, 2025
    What to do if STERO Dishwasher won't start?
    • H
      Heidi JohnsonAug 18, 2025
      If your STERO Dishwasher isn't starting, first, ensure the machine is turned on. Check the fuse or circuit breaker at the power supply. Also, verify the tank water level.
  • J
    James SharpAug 21, 2025
    Why is there spotting on silverware, glasses, and dishes in my STERO Dishwasher?
    • C
      Cynthia ReyesAug 21, 2025
      Spotting on your silverware, glasses, and dishes from your STERO Dishwasher could be due to several reasons. Ensure you scrape dishes before the cycle begins. If there is loss of water pressure due to pump obstruction, disconnect the electrical power supply (both dishwasher and booster if applicable) and drain the tank. The issue might also be excessively hard water.
  • F
    fishercharlesAug 25, 2025
    What to do if my STERO Dishwasher has no wash tank heat?
    • W
      William ReedAug 25, 2025
      If there's no wash tank heat in your STERO Dishwasher, check for proper water level and make sure the fuse isn't blown, or the circuit breaker hasn't tripped at the power supply.
  • K
    Karl HernandezAug 28, 2025
    What to do if my STERO Dishwasher has inadequate rinse water temperature or rinse?
    • J
      johnsonannaAug 28, 2025
      If your STERO Dishwasher has inadequate rinse or the rinse water temperature is too low, and you see a possible EE display, it might be due to a dirty line strainer. Turn off the water supply, remove the strainer cap, withdraw and clean the screen, then reassemble. Deliming may be necessary if there are excessive mineral deposits throughout the wash and rinse system. You can also try pressing OFF, waiting 5 seconds, and then pressing ON again. The machine will automatically extend wash time until the booster heats up (this applies to SD3 booster equipped machines only).
  • T
    thompsonmaryAug 31, 2025
    What to do if my STERO Dishwasher is not filling or filling slowly?
    • P
      Peter TuckerAug 31, 2025
      If your STERO Dishwasher is not filling or filling slowly, and you see a possible E2 display, debris may be obstructing the standpipe movement, allowing fill water to drain. Turn off the hot water supply, remove the strainer cap, withdraw and clean the screen, then reassemble. Make sure the hot water supply valve is open. You can also try pressing OFF, waiting 5 seconds, and then pressing ON again.
  • J
    jonesrebeccaSep 3, 2025
    What does Ed display mean on my STERO Dishwasher?
    • M
      Mr. Adam RodriguezSep 3, 2025
      If your STERO Dishwasher displays 'Ed', make sure the drain lever is closed, the standpipe is seated, and the O-ring is clear of all food soil or other debris.
  • S
    Scott MccarthySep 6, 2025
    What to do if my STERO Dishwasher valve is leaking?
    • S
      Sheila MasseySep 6, 2025
      If your STERO Dishwasher valve is leaking, shut off the supply line. Unscrew and lift the bonnet from the valve body, clean the valve, and reassemble it. The leak may be caused by foreign material preventing proper valve operation.
  • Y
    yrojasSep 9, 2025
    Why is water dribbling from the lower rinse arm of my STERO Dishwasher?
    • D
      daisygordonSep 10, 2025
      If your STERO Dishwasher is equipped with an electric booster, normal dripping from the lower rinse arm will occur during water heating due to the expansion of the water. This will occur once between machine cycles.

Summary

GENERAL

START-UP CHECKLIST

BEFORE POWER IS APPLIED

Steps to perform before applying electrical power to the unit.

AFTER POWER IS APPLIED AND WATER TURNED ON

Checks after power and water are connected and supplied.

RUN A 1 MINUTE CYCLE

Procedure for running a short operational test cycle.

INSTALLATION

UNPACKING AND INSTALLATION CODES

Checking for shipping damage and adhering to installation codes.

LOCATION AND CLEARANCES

Selecting site, leveling, and ensuring proper clearances.

INSTALLATION (continued)

CORNER INSTALLATION

Specific requirements and adjustments for corner installations.

INSTALLATION (continued)

WATER REQUIREMENTS

Recommended water quality parameters and treatment for optimal operation.

PLUMBING CONNECTIONS

Details on connecting the drain and water supply lines.

INSTALLATION (continued)

WATER SUPPLY CONFIGURATIONS

Incoming water temperature and pressure for models with/without electric booster.

INSTALLATION (continued)

VENTING REQUIREMENTS

Guidelines for exhaust hood and venting requirements for the dishwasher.

INSTALLATION (continued)

ELECTRICAL CONNECTIONS

Detailed instructions and data for making electrical connections.

PUMP MOTOR ROTATION

Procedure to check and reverse pump motor rotation on 3-phase machines.

INSTALLATION (continued)

BOOSTER AND EQUIPMENT CONNECTIONS

Electrical connections for boosters and external equipment controls.

INSTALLATION (continued)

DISPENSER TUBING INSTALLATION

Instructions for installing tubing for detergent, rinse aid, and sanitizer dispensers.

INSTALLATION (continued)

DISPENSER EQUIPMENT CONNECTIONS

Wiring terminals and connections for detergent, rinse aid, and sanitizer dispensers.

INSTALLATION (continued)

SD3 SETUP AND SANITIZING MODES

How to configure the dishwasher's sanitizing mode selection.

OPERATION

PREPARATION

Steps to prepare the dishwasher for operation, including strainer and ON button.

DISHWASHING PROCEDURE

How to load racks and run wash cycles.

OPERATION (continued)

DISHWASHING DETAILS

Detailed instructions on loading racks and running wash cycles.

CLEANING

DAILY CLEANING STEPS

Daily cleaning steps for the dishwasher interior, arms, and strainers.

CLEANING (continued)

DOS AND DONTS FOR USAGE

Recommendations and prohibitions for using the dishwasher to ensure proper function.

DELIME AND WASH ARM MAINTENANCE

How to perform deliming and maintain wash arms.

TROUBLESHOOTING

No Machine Operation

Possible causes and solutions for the machine not operating.

Dishes Not Clean

Reasons why dishes may not be getting clean and how to fix them.

Spotting Issues

Causes of spotting on dishes and how to resolve them.

Inadequate Rinse or Low Rinse Temperature

Issues related to low rinse temperature or inadequate rinsing.

EE Display Error

Troubleshooting steps for the 'EE' display error code.

TROUBLESHOOTING (continued)

Leaking Valve

Troubleshooting steps for leaking valves.

Fill and Heat Issues

Problems related to no/slow fill and no wash tank heat.

Dribbling Rinse Arm

Explains normal dripping and when to troubleshoot continuous leaks.

Indicator Lights and Codes

Troubleshooting display errors (E2, Ed, E6) and indicator lights.

SERVICE

STERO ML-130232 Specifications

General IconGeneral
BrandSTERO
ModelML-130232
CategoryDishwasher
LanguageEnglish
