StetSom BRAVO Full 2000 - Installation Procedure; Recommended Cable Specifications; Fuse;Circuit Breaker Mandatory Use; Installation Safety Warning

6
Installaon should only be done by qualied professionals with the
product turned OFF.
Instalation

connectors........................................
Remote connector ......................................................................
 ..........................................
 ..............................................................
The use of a fuse or circuit breaker is mandatory to protect the system from short
circuits and overload. Install them as close to the baery as possible.
4 AWG
18 AWG
9 AWG
120A
REM
Radio / Player
18 AWG cable
Baery
RECOMMENDED USE
OF AUXILIARY BATTERY.
(maximum
12” of baery)
STETSOM
REM (remote)
POWER
GROUND
4 AWG cable
4 AWG cable
Fuse
120A
Ground
