17.3 Domestic hot water output
The DHW output is subject to the connected power supply, the
appliance's connected load and the cold water inlet temperature.
The rated voltage and rated output can be found on the type plate.
Connected load in kW 38°C DHW output in l/min
Rated voltage Cold water inlet temperature
380V 400V 415V 5°C 10°C 15°C 20°C
DHB-E 11/13 LCD
9.9 4.3 5.1 6.1 7.9
12.2 5.3 6.2 7.6 9.7
11 4.8 5.6 6.8 8.7
13.5 5.8 6.9 8.4 10.7
11.8 5.1 6.0 7.3 9.4
14.5 6.3 7.4 9.0 11.5
DHB-E 18 LCD 25A
16.2 7.0 8.3 10.1 12.9
18 7.8 9.2 11.2 14.3
19.4 8.4 9.9 12.0 15.4
DHB-E 18/21/24 LCD
16.2 7.0 8.3 10.1 12.9
19 8.2 9.7 11.8 15.1
21.7 9.4 11.1 13.5 17.2
18 7.8 9.2 11.2 14.3
21 9.1 10.7 13.0 16.7
24 10.4 12.2 14.9 19.0
19.4 8.4 9.9 12.0 15.4
22.6 9.8 11.5 14.0 17.9
25.8 11.2 13.2 16.0 20.5
DHB-E 27 LCD
24,4 10,6 12,4 15,2 19,4
27 11,7 13,8 16,8 21,4
Connected load in kW 50°C DHW output in l/min
Rated voltage Cold water inlet temperature
380V 400V 415V 5°C 10°C 15°C 20°C
DHB-E 11/13 LCD
9.9 3.1 3.5 4.0 4.7
12.2 3.9 4.4 5.0 5.8
11 3.5 3.9 4.5 5.2
13.5 4.3 4.8 5.5 6.4
11.8 3.7 4.2 4.8 5.6
14.5 4.6 5.2 5.9 6.9
DHB-E 18 LCD 25A
16.2 5.1 5.8 6.6 7.7
18 5.7 6.4 7.3 8.6
19.4 6.2 6.9 7.9 9.2
DHB-E 18/21/24 LCD
16.2 5.1 5.8 6.6 7.7
19 6.0 6.8 7.8 9.0
21.7 6.9 7.8 8.9 10.3
18 5.7 6.4 7.3 8.6
21 6.7 7.5 8.6 10.0
24 7.6 8.6 9.8 11.4
19.4 6.2 6.9 7.9 9.2
22.6 7.2 8.1 9.2 10.8
25.8 8.2 9.2 10.5 12.3
DHB-E 27 LCD
24,4 7,7 8,7 10,0 11,6
27 8,6 9,6 11,0 12,9
17.4 Application areas/ Conversion table
Specific electrical resistance and specific electrical conductivity
Standard specifica-
tion at 15°C 20°C 25°C
Resist-
ance
ρ≥
Conductivity σ ≤ Resist-
ance
ρ≥
Conductivity σ ≤ Resist-
ance
ρ≥
Conductivity σ ≤
Ωcm mS/m μS/cm Ωcm mS/m μS/cm Ωcm mS/m μS/cm
900 111 1111 800 125 1250 735 136 1361
17.5 Pressure drop
Taps/valves
Tap pressure drop at a flow rate of 10 l/min
Mono lever mixer tap, approx. MPa 0.04 - 0.08
Thermostatic valve, approx. MPa 0.03 - 0.05
Shower head, approx. MPa 0.03 - 0.15
Sizing the pipework
When calculating the size of the pipework, an appliance pressure
drop of 0.1MPa is recommended.
17.6 Fault conditions
In the event of a fault, loads up to 80°C at a pressure of 1.0 MPa
can occur briefly in the installation.
