STIEBEL ELTRON EVS15 User Manual

~ 5 ~
Technical data
Model
EVS15
EVS30
EVS50
EVS80
EVS100
EVS150
Type
Close
Outlet pressure
0.7 Mpa (7 bar)
Water Connector
G 1/2"
Power Supply
1/N/PE AC 220-240V
Rated frequency
50-60 Hz
220 V
kW
1.5
2.0
230 V
kW
1.63
2.18
240 V
kW
1.78
2.38
Cable Size (Sq.mm)
2.5-4
Circuit Breaker (A)
10
15
Thermal cut out (TCO)
Manual Reset ( 93°C +2°C / -5°C )
Thermostat
30°C to 75°C
Insulation layer
Polyurethane
Anode
Magnesium stick
Dimension (mm)
Ø305x543
Ø365x611
Ø390x745
Ø460x 740
Ø460x880
Ø460x1230
Unit weight (kg)
10.8
12.6
17.1
23.3
27.6
37.9
