8 ~
Cause Analysis
1. Heating Elements
Checking
Definition:
Heating element is a metal coil that heats up to high temperatures when electricity
is applied.
-
Disconnect cables to the element
s.
- Set Multi
)
)
)
)
Check
Meter Result
Cause
Action
Pole-Pole
"Beep" signal "
)
)
)
) "
Pass
No action
No signal "OL" or (
Element Broken
Change New Heater
Pole-Case
"Beep" signal "
)
)
)
) "
Element Broken
Change New Heater
No signal "OL" or (
Pass
No action
Remark: "OL" =
Over Load
For
Digital
multimeter
And "
For
Analog multimeter
Pole -Pole
Pole -Case
Case
Pole
Pole 1
Pole 2
7
9
