1.2. PRODUCT DESCRIPTION
The robot lawn mower is designed to mow the grass around
areas of the garden delimited by the perimeter cable.
The operating principle is based on random navigation. The
robot lawn mower changes trajectory whenever the perimeter
cable or an obstacle is detected.
Any other usage may be hazardous and harm persons and/
or damage things. Improper use includes (for example, but
not limited to): transporting people, children or animals on
the machine; being transported by the machine; using the
machine to pull or push loads; using the machine for cutting
non-grass vegetation.
1.3. SYMBOLS AND NAMEPLATES
WARNING:
Read the user instructions before starting
the product.
WARNING:
Danger of projections of objects against
the body.
Keep an adequate safe distance from the
WARNING:
Do not put hands and feet near or under the
opening of the cutting means.
Remove the disabling device before operating
on the machine or before lifting it.
WARNING:
Do not put hands and feet near or under the
opening of the cutting means.
Do not stand on the machine.
BAN:
Make sure that there are no people (especially
machine.
BAN:
Do not use high pressure cleaners on the
1.4. STOPPING AND TURNING OFF THE ROBOT
LAWN MOWER IN SAFE CONDITIONS
OBLIGATION:
maintenance operation.
1. Press the “STOP” push button (Fig. 1.A) to stop the robot
lawn mower safely and open the protective cover (Fig. 1.B).
2. Remove the safety key (Fig. 1.D) to switch o the robot
lawn mower in safe conditions.
3. Close the protective cover (Fig. 1.B).
4. The robot lawn mower is stopped or switched o in a
safe condition.
2. INSTALLATION
WARNING:
the safety devices installed.
NOTE: For further clarication on the installation of the
product please contact a STIGA dealer.
(A) Charging base, (B) Power supply, (C) Perimeter cable,
(D) Perimeter cable xing pegs, (E) Fixing screws for the
charging base, (F) Joint for perimeter cable, (G) Charging
base connectors
2.1. VERIFICATION OF THE INSTALLATION
2.1.1. GARDEN ASSESSMENT:
• Check the garden condition in accordance with Chap. 1.
• Level the ground so that no puddles form as a result of rain.
2.1.2. CHECKS FOR THE INSTALLATION OF THE
CHARGING BASE AND POWER SUPPLY:
ELECTRICAL HAZARD:
It is absolutely necessary to provide an
ELECTRICAL HAZARD:
The circuit provided must be protected by
activation current not exceeding 30 mA.
ELECTRICAL HAZARD:
electrical outlet if the plug or the cable is
damaged.
Do not connect or touch a damaged cable
supply.
live parts.
1. Provide a at surface at the edge of the lawn to position
the charging base.
2. Ensure that the distance of the base from any bends is
at least 200 cm.
WARNING:
belong to the product must remain outside the
cutting area to maintain their distance from
hazardous moving parts and prevent damage
live parts.
3. Set up the installation area of the power supply unit in
such a way as to prevent it from being submerged by
water under all weather conditions. Preferably install in a
closed room and protected from weather conditions, in a
location not easily accessible by unauthorised persons.
