DETAIL A
ASSEMBLY TIP
4
2. Press the tab on the Safety Latch (#30) to unlock the H leg (#19) and raise
the Front legs (#15) until they are in the vertical position. See DETAIL A.
Safety Latch
1
15
19
30
DO NOT pull up from legs (#19)
because you can damage the table.
These legs raise automatically when
Front Legs (#15) are raised.
1. Lay Table Top (#1) painted side down, on a smooth, flat surface.
CAUTION: Make sure that the table top is secure on the
sawhorses and NEVER leave the table top unattended.
Table top can be set on two saw horses. Although this will make
assembly easier it is not necessary to complete assembly. Always use
shipping container to protect the painted surface of the table top.
Raise the Front legs
(#15) until they are in
the vertical position
To Next Page
