Stiga T8623 - Replacement Parts List

24
38
24
34
33
29
34
37
8
13
14
10
16
17
16
8
9
16
27
12
39
32
17
17
31
28
36
13
43
28
16
17
15
11
15
2L-4134-02
Replacement Parts List for Model Number T8623
5
30
38
34
22
3437
18
19
2
5
5
5
24
23
23
40
5
2
3
Key# Part # T8623 Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
Qty.
4A-5523-00
2S-4644-04
2S-4645-04
3M-4166-02
1B-4082-99
3M-6273-00
NOT USED
8S-6841-09
2Q-4023-02
2Q-4024-02
2B-4043-00
3M-6884-00
1B-6195-00
3M-6274-00
2W-6258-02
8S-6842-02
8S-6850-07
4A-5423-02
1A-4107-00
2S-4597-01
8S-6851-04
2S-6879-10
2S-4661-00
1B-4137-00
2S-6343-00
3M-4147-00
1B-6495-00
2B-4053-00
1B-4138-00
1B-4097-01
1B-6459-00
1N-0001-00
WB-1007-99
2B-4047-98
1B-4089-00
7B-4061-00
7B-6161-00
2B-6087-00
2B-4054-00
3M-4165-00
5A-6700-01
2L-4134-02
2S-6875-01
3/4" Indented Top - Black
Side Rail - Right Hand
Side Rail - Left Hand
Storage Tray Assembly
#8 x 9/16" Sheet Metal Screw
U-Support Clip (Plastic)
NOT USED
Caster Beam Only
3" Caster - Non Locking
3" Caster - With Lock
3/8" Push Nut
Stop Spool
3/8-16 x 2 3/4" Hex Head Bolt
Tube Plug - 1" x 2”
Bottom Board
Linkage
Strut Tube
Hinge & Mounting Bracket Assembly
Leg with Brace Assembly
Mounting Bracket
U-Support
1" U-Clip
End Rail
1/4-20 x 2 1/2" Hex Head Bolt
Leg Mounting Bracket - 1”
1 3/4" Leg Cap
3/8-16 x 3 1/2" Hex Head Bolt
3/8-16 Nyloc Jam Nut
#10-24 x 1/2" Phillips Pan Head Screw
1/4-20 x 1 1/2" Phillips Truss Head Screw
1/4-20 x 3 1/4 Crriage Bolt
1/4-20 Wing Nut
#10-24 Locknut
1/4-20 Nyloc Jam Nut
#8-32 x 1 1/4 Sheet Metal Screw
5/8 OD x 3/8 ID x 3/4" Long Spacer
1/2 OD x 1/4 ID x 3/8" Long Spacer
1/4" Plastic Washer
3/8" Plastic Washer
Corner Protector
66" Net & Posts Set (Not Shown)
Owners Manual - T8623
Support Plate - Black
2
2
2
2
164
8
2
2
2
4
8
8
4
1
4
4
4
4
4
2
6
4
8
4
4
4
12
4
4
4
4
4
12
4
4
4
12
8
4
1
1
4
6
21
20
25
1
40
26
20
25
4
