Edition Manual Chapter Page
2008-05-19 Workshop Manual, Stiga Villa/Ready 5 Belts 1
5 Belts
Contents in this chapter
General
All mechanical power, delivered by the motor, is conducted to the different power
consuments by a belt system. The belt system has in general the same configuration in all
the machines covered by this manual. Where divergences occour between the machines,
particular instructions are given for each machine. The maximum tension of each belt is
regulated by a spring loaded belt tensioner.
This chapter gives a brief description of the belt system and describes replacements of
belts and adjustments of their tensions.
This chapter is valid for the actual machines where the actual system occur.
5.4 Adjustments...............................9
5.4.1 Adjustment of belt B ...............9
5.4.2 Adjustment of the
clutch/brake, HST....................10
5.4.3 Adjustment of the clutch, Man 10
5.1 Description................................. 2
5.2 Belt theory..................................3
5.2.1 Why it is so important to use
original belts from
the retail dealer? ..................... 3
5.3 Replacement of belts ................5
5.3.1 Disassembly of belt D ............ 5
5.3.2 Inspection and measures ....... 7
5.3.3 Assembly of belt D ................. 7
