Edition Manual Chapter Page
2008-05-19 Workshop Manual, Stiga Villa/Ready 6 Control wires 1
6 Control Wires
Contents in this chapter
General
All the manoeuvring functions are collected around the operator.
All mechanical control movements from the operator to the respective device on the ma-
chine are conducted by wires or rods.
This chapter gives a brief description about the wires and information about how to re-
place and adjust the wires.
This chapter is valid for the actual machines where the actual system occur.
6.4 Throttle wire .............................. 4
6.4.1 Dismantling ............................ 4
6.4.2 Assembly ............................... 4
6.4.3 Adjustment............................. 4
6.1 Description.................................2
6.2 Cable holders.............................2
6.3 PTO wire.....................................3
6.3.1 Dismantling.............................3
6.3.2 Checks ...................................3
6.3.3 Assembly................................3
6.3.4 Adjustment .............................3
