Edition Manual Chapter Page
2008-05-19 Workshop Manual, Stiga Villa/Ready 7 Electrical System 1
7 Electrical System
Contents in this chapter
General
Each machine has its own electrical system, configurated to fit the purpose and demand of
the actual machine. The electrical system has two main duties, to maintain the machine
safety and to make the different functions easy to handle.
The main part of this chapter consists of trouble shooting of the electrical system to isolate
faults and to give information about corrective measures. The electrical system is also
described. There are also given instructions about general repair and replacement
procedures.
7.1 Description................................. 2
7.2 Trouble Shooting ...................... 3
7.3 Repair and replacements.......... 16
7.3.1 Replacement of switches ....... 16
7.3.2 Replacement of switch knob .. 16
7.3.3 Connections ........................... 16
