Main Parts of the Saw
1 = Twist lock
2 = Spark plug boot
3 = Decompression valve *
4 = Chain brake
5 = Chain sprocket
6 = Chain sprocket cover
7 = Chain catcher
8 = Chain tensioner
9 = Adjusting wheel of quick tensioner *
10 = Bumper spike
11 = Guide bar
12 = Oilomatic saw chain
13 = Oil filler cap
14 = Muffler
15 = Front hand guard
16 = Front handle (handlebar)
17 = Starter grip
18 = Fuel filler cap
19 = Master Control lever
20 = Throttle trigger
21 = Throttle trigger interlock
22 = Rear handle
23 = Rear hand guard
* Special accessory
7
8
10
9
1
3
12
9
4
11
6
143BA049 KN
2
5
22
21
20
19
18
13
17
16
23
15
14
143BA050 KN
2 017, 018
