Stihl 023 Service & Repair Manual

Online version - not for reprint
•
Fitthewasheronthepivotpin.
•
Fitstraponthepivotpin(1)
andlocateitinthepivotpin’s
groove.
•
Sliptheotherendofthestrap
overthebellcrankpivotpin(2).
-SecurestrapwithE-clip.
-Coatbrakebandwithchainoil
(STIHLBioplus),see11.2,to
protectitfromcorrosionandhelp
reduce"snatching"duringthe
firstfewbrakeapplications.
•
Hookthebrakespringontothe
bellcrank.
•
Positionthebrakebandaround
theclutchandpushitintothe
enginehousing.
•
Attachthebrakespringtothe
bellcrank.
•
Usetheassembly(2)
11178900900toattachthe
brakespring(1)totheanchor
pin.
-Fitthebushinginthehandguard.
-InsertM5x24screwandtighten
downto3.5Nm(2.6lbf.ft).
•
On023L,pushtherubber
bushing(1)intothehandguard
(2).
-InsertM5x32screw(3)and
tightendownto3.7Nm
(2.8lbf.ft).
-Fitthecover.
-Tightenscrewsto2.0Nm
(1.5lbf.ft).
-Installclutchdrum/chain
sprocket-see4.1.
-Checkoperationofchainbrake-
see4.4.1.
VA
135RA031
VA
135RA038
VA
135RA041
1
2
VA
135RA037
1 2
VA
135RA039
VA
135RA042
1
2
3
V
A
13
5R
A
04
0
021,023,025 11
