BR 500, BR 550, BR 600
English
13
N Remove the cap.
Filling up with fuel
Take care not to spill fuel while fueling
and do not overfill the tank.
STIHL recommends you use the STIHL
filler nozzle for fuel (special accessory).
N Filling up with fuel
Closing tank cap with hinged grip
Grip must be vertical:
N Fit the cap in the opening – the
marks on the cap and filler neck
must line up.
N Press the cap down as far as stop.
N While holding the cap depressed,
turn it clockwise until it engages in
position.
N Fold the grip flush with the top of the
cap.
Checking security of cap
– The lug on the grip must fully
engage the recess (arrow).
N Grip the cap – it is properly locked if
it cannot be turned or removed.
If the cap can be turned or removed
Bottom of cap is twisted in relation to
top:
