Stihl FS 110 Manual

16 Series 4180 Powerhead
– Remove the rewind starter,
b 5.2
– Remove remaining rope from the
rope rotor and starter grip.
: Thread end of new rope through
the underside of the starter grip
and pull it out.
: Secure the end of the rope with
one of special knots shown.
– Pull the rope back into the starter
grip.
VA
982RA036
– Thread the other end of the rope
through the guide bush (2) from
outside.
– Thread the rope through the hole
in the side of the rope rotor (1).
: Pull out the rope and secure it
VA
249RA028
1
2
with a simple overhand knot.
: Pull the rope back into the rotor
so that the knot locates in the
recess (1).
– Tension the rewind spring,
b 5.4.1
1
VA
249RA029
5.4 Starter Rope

Stihl FS 110 Specifications

General

Engine Displacement	31.4 cc
Fuel Type	Gasoline
Handle Type	Bike handle
Shaft Type	Straight
Engine Type	2-stroke
Starter	Recoil
Weight	5.8 kg
Engine Power	1.05 kW (1.4 bhp)
Overall Length	180 cm (70.9 in)
