Stihl FS 120 User Manual

32
English / USA
FS 120, FS 120 R, FS 200, FS 200 R, FS 250, FS 250 R
Change the fuel pickup body every
year.
Before storing your machine for a long
period, drain and clean the fuel tank.
Run the engine until the carburetor is
dry.
The type and style of harness depend on
the market.
Shoulder Strap
: Put on the shoulder strap (1).
: Adjust the length of the strap so that
the spring hook (2) is about a hand’s
width below your right hip.
: Balance the brushcutter.
The use of the harness is described in
chapter “Approved Combinations of
Cutting Tool, Deflector, Handle and
Harness”.
Full harness
: Put on the full harness (1).
: Adjust length until the spring hook
(2) is about a hand’s width below
your right hip.
: Balance the brushcutter.
The use of the harness is described in
chapter “Approved Combinations of
Cutting Tool, Deflector, Handle and
Harness”.
250BA051 KN
Fitting the Harness

Stihl FS 120 Specifications

General

Power source	Gasoline
Type	Brush cutter
Cordless	Yes
Head type	Nylon line
Handle type	U-type handle
Engine power	1.8 hp
Product color	Black, Metallic, Orange
Uncertainty K	2 m/s²
Sound power level	110 dB
Fuel tank capacity	0.64 L
Vibration emission	4.9 m/s²
Engine displacement	30.8 cm³
Sound pressure level	98 dB
Cutting diameter (max)	- mm

Weight and Dimensions

Length	1760 mm
Weight	6300 g
