0478 201 8313 B - EN
6
3. Machine overview
1 Upper chute
2 Lower chute
3 Closure screws
4 Basic unit
5 Ejection chute
6 On/off switch with mains connection
7 Wheels
8 Wheel carrier
9 Rating plate with machine number
