0458-694-8621-A
4
English
4 Safety Symbols on the Products
1 Gripping Surface
For the operator's front hand.
2Guard
Helps protect against contact with the saw chain.
3 Chain Scabbard
Covers the guide bar and saw chain to reduce the risk of
injury from inadvertent contact during transportation and
storage
4Bumper
Helps hold the garden pruner steady against the branch
or limb during cutting.
5 Trigger Switch Lockout
Prevents activation of the trigger switch until depressed.
6 Saw Chain
Toothed cutting tool consisting of cutters, tie straps and
drive links.
7 Guide Bar
Supports and guides the saw chain.
8 Chain Sprocket
Drives the saw chain.
9 Wingnut
Tightens the chain sprocket cover.
10 Chain Sprocket Cover
Covers the chain sprocket.
11 Garden Pruner LEDs
Indicate the battery's state of charge and display error
messages regarding potential malfunctions in the power
tool or battery.
12 Push Button
Activates the garden pruner's LEDs.
13 Trigger Switch
Switches the motor on and off.
14 Control Handle
Handle for the operator's rear hand.
15 Battery Compartment
Holds the battery.
16 Battery
Supplies electrical power to the motor.
17 Locking Hook
Secures the battery in the battery compartment.
18 Charger
Charges the battery.
19 Charger LED
Indicates the operating status of the charger.
20 Power Supply Cord
Supplies the charger with electricity when plugged into
an electrical outlet.
21 Plug
Connects the power supply cord to an electrical outlet.
22 Carrying Bag
Included when the garden pruner, battery and charger
are purchased as a set.
# Rating Plate
Contains electrical information and the product's serial
number.
4.1 Garden Pruner, Battery and Charger
The following safety symbols are found on the garden
pruner, battery and/or charger:
4 Safety Symbols on the Products
To reduce the risk of injury, follow the specified
safety precautions.
