Page 8 Technical Information 10.2011
TI_10_2011_30_01_01.fm
8. Summary
© ANDREAS STIHL AG & Co. KG, 2011 Technical Documentation
D1/MTK-bl
Item Part Name Previous New Rem.
1 Fuel tank 4180 350 0424 - - - 1)
2 Toolless filler cap 0000 350 0535 - - - 2)
3 Fuel tank; including items 4 and 7 - - - 4180 350 0432 3)
4 Threaded filler cap 0000 350 0517
5 Shroud including items 6 and 7 4180 080 1604 4180 080 1605 1) 4)
6 Pictogram 0000 967 3605 - - - 2) 4)
7 Pictogram - - - 0000 967 7222 4)
8 Throttle cable; including item 14 4180 180 1100 4180 180 1150 1)
9 Throttle cable; including item 14 4180 180 1101 4180 180 1151 1)
10 Throttle cable; including item 14 4180 180 1104 4180 180 1152 1)
11 Throttle cable; including item 14 4180 180 1105 4180 180 1153 1)
12 Throttle cable; including item 14 4280 180 1100 4280 180 1150 1)
13 Tensioner 4180 182 7600 - - - 1)
14 Tensioner - - - 4180 182 7601
15 Ignition module 4180 400 1300 4180 400 1308 1) 4)
16 Fan housing; including item 17 4180 080 1801 4180 080 1809 1)
17 Rivets 9416 868 6510 - - - 2)
18 Drive shaft 4137 710 3202 4137 711 3202 1) 4)
19 Flexible liner 4134 711 7301 4137 711 7300 1) 4)
Modification to be introduced : continuously
Remarks
1) Previous version of part no longer available from factory
2) Previous version of part remains available for older models
3) New version of part can also be used for older machines
4) see “Service Notes”
