Stihl HS 75 - Repair Times; Replacement Parts

Andreas Stihl - D1/MTK-al
Technical Documentation 5773
© 1996 Andreas Stihl
 7LJKWHQLQJWRUTXHV
Fastener Thread size For component Tightening
torque (Nm)
Spline screw IS-M 5x25 Crankcase 9.5
Spline screw IS-M 5x25 Crankcase
Crankcase spacer flange/cylinder 5.5
Spline screw IS-DG 5x24 Cylinder/crankcase 9.5
Spline screw IS-M 4x16 Brake band/gear housing 3.5
Spline screw IS-M 4x16 Gearbox cover/gear housing 3.5
Spline screw IS-M 5x16 Muffler/cylinder 9.5
Spline screw IS-M 5x16 Air cowling/gear housing 5.5
Spline screw IS-M 5x16 Gear housing/crankcase 5.5
Spline screw IS-M 5x16 Starter cover/crankcase 5.5
Spline screw IS-M 5x16 Muffler/crankcase 9.5
M 8 Starter carrier 20.0
Nut M 8 Clutch 21.0
Spline screw IS-M 4x20 Ignition module/cylinder 4.5
Plastoform screw IS-P 5.5x12 Rope rotor in starter cover 3.5
Spline screw IS-M 5x16 Cutting blade 9.5
Spline screw IS-M 5x20 Blade guide/gear housing (HS 75, 80) 9.5
Spline screw IS-M 5x25 Blade guide/gear housing (HS 85) 9.5
Spline screw IS-M 5x25 Eccentric lever/gear housing 5.5
Spline screw IS-M 5x18 Rubber buffer/
handle moulding (HS 75, 80) 3.5
Spline screw IS-M 5x16 Rubber buffer/gear housing (HS 85) 5.5
Spark plug M 14x1.25 20.0
Plastoform screw IS-P 4x19 Handle moulding (HS 75, 80) 2.0
Spline screw IS-M 5x30 Handle halves (HS 85) 2.5
 5HSDLUWLPHV
The same repair times apply for the HS 75, 80, 85
models as for the HS 72, 74 and 76 models.
 5HSODFHPHQWSDUWV
A separate parts list is available for the new mo-
dels.
7HFKQLFDO,QIRUPDWLRQ3DJH
