0458-601-8621-A
3
English
3 Main Parts
WARNING
Indicates a hazardous situation that, if not avoided, could
result in death or serious injury.
NOTICE
Indicates a risk of property damage, including damage to the
machine or its individual components.
2.2 Symbols in Text
The following symbol is included to assist you with the use
of the manual:
3.1 Garden Shears, Battery and Charger
1 Carrying Bag
Designed for transporting and storing the garden shears,
battery, charger and accessories. The carrying bag is
included when the garden shears, battery and charger
are purchased as a set.
2 Retaining Latch
Locks/unlocks the trigger switch.
3 Control Handle
The garden shears‘ handle.
4 Battery Compartment
Holds the battery.
Refers to a designated chapter or sub-chapter in this
instruction manual.
3 Main Parts
5
6
7
#
8
1
2
3
4
9
10
11
#
#
12
13
0000-GXX-B575-A0
