0458-714-8221-A
3
English
3 Main Parts
WARNING
Indicates a hazardous situation that, if not avoided, could
result in death or serious injury.
NOTICE
Indicates a risk of property damage, including damage to the
machine or its individual components.
2.2 Symbols in Text
The following symbol is included to assist you with the use
of the manual:
3.1 Hedge Trimmer, Battery and Charger
1 Loop Handle
Handle for the operator's front hand.
2 Switch Lever
Activates the cutting attachment when depressed in
combination with the trigger switch.
3 Battery Compartment
Holds the battery.
Refers to a designated chapter or sub-chapter in this
instruction manual.
3 Main Parts
1
10
9
2
3
4
5
8
7
12
17
16
15
13
14
11
#
6
#
#
0000-GXX-1451-A0
