0458-714-8221-A
4
English
4 Safety Symbols on the Products
4 Locking Lever
Secures the battery in the battery compartment.
5 Retaining Latch
Locks/unlocks the trigger switch.
6 Trigger Switch Lockout
Must be depressed while the retaining latch is unlocked
to allow activation of the trigger switch.
7 Control Handle
Handle for the operator's rear hand.
8 Trigger Switch
Activates the cutting attachment when depressed in
combination with the switch lever.
9 Hand Guard
Helps protect the operator's front hand from projecting
branches and other materials and contact with the
cutting blades.
10 Cutting Blades
Steel blades for cutting hedges, shrubs and bushes.
11 Charger
Charges the battery.
12 Charger LED
Indicates the operating status of the charger.
13 Plug
Connects the power supply cord to a wall outlet.
14 Power Supply Cord
Supplies the charger with electricity when plugged into a
wall outlet.
15 Battery
Supplies electrical power to the motor.
16 Battery LEDs
Indicate the battery's state of charge and display error
messages regarding potential malfunctions in the battery
or power tool.
17 Push Button
Activates the battery's LEDs.
# Rating Plate
Contains electrical information and the product's serial
number.
4.1 Hedge Trimmer, Battery and Charger
The following safety symbols are found on the hedge
trimmer, battery and/or charger:
4 Safety Symbols on the Products
To reduce the risk of injury, follow the specified
safety precautions.
Read and follow all safety precautions in the
instruction manual. Improper use can lead to
serious or fatal personal injury or property
damage.
To reduce the risk of eye injury, always wear
proper eye protection, @ 6.3.
To reduce the risk of cut injuries, keep hands,
feet and other body parts away from the cutting
blades, @ 6.5.4.
To reduce the risk of injury or property damage
from unintended activation, remove the battery
any time the hedge trimmer is not in use, @ 6.4.
