Stihl HT 56 C User Manual

HT 56 C
English
40
1 Manual Fuel Pump
2 Fuel Filler Cap
3 Fuel Tank
4 Starter Grip
5 Muffler with Spark Arresting Screen
6 Coupling Sleeve
7 Wing Screw
8 Drive Tube with Handle Hose
9 Carrying Ring
10 Stop Switch
11 Throttle Trigger
12 Throttle Trigger Lockout
13 Carburetor Adjusting Screws
14 Choke Lever
15 Air Filter Cover
16 Spark Plug Boot
17 Machine Support
18 Oilomatic Saw Chain
19 Guide Bar
20 Oil Tank
21 Oil Filler Cap
22 Drive Tube
23 Sleeve
24 Chain Sprocket Cover
25 Hook
26 Chain Guard (Scabbard)
27 Chain Sprocket
28 Chain Tensioner
# Serial Number
Main Parts
16
17
11
20
21
22
23
26
25
24
28
27
13
14
15
18
19
8
6
22
7
10
12
#
9
4907BA012 KN
2
1
4
5
3

Stihl HT 56 C Specifications

General

Engine Power	0.8 kW (1.1 hp)
Displacement	27.2 cm³
Overall Length	280 cm
Chain Type	Picco Micro 3 (PM3)
Guide Bar Length	25 cm
Power Source	Gas
Fuel Capacity	340 cc (11.5 oz.)
